Kramer KDock-4 USB–C Hub Multiport Adapter

Kramer KDock-4 USB-C hub
Multiport adapter speciaal ontworpen om mobiele apparaten te ondersteunen en is een ideaal accessoire voor . Met KDock-4 kunt u uw USB-C-apparaat aansluiten op HDMI ™, DisplayPort en VGA-video-uitgangen, 2 USB 3.0-poorten, 1 USB 2.0-poort, een Ethernet-poort, SD- en micoSD-kaartpoort en USB-C-oplaaddoorvoer .
Opmerking: video-uitgang voor smartphones wordt alleen ondersteund voor smartphones die de DisplayPort Alt-modus via USB-C ondersteunen.

INGANGEN
1 USB: On a USB Type–C male connector

UITGANGEN
1 HDMI: On a female HDMI connector
1 DisplayPort: On a female DisplayPort connector
1 VGA: On a female 15–pin HD connector

POORTEN
2 USB 3.0: On female USB type–A connectors
1 USB 2.0: On female USB type–A connectors
1 Ethernet: On an RJ–45 connector
SD: On an SD card port
1 Unbalanced Stereo: On a 3.5mm mini jack
SD: On a microSD port
1 USB: On a female USB type–C connector for charging

VIDEO
Max Resolution (HDMI/DP): 3840x2160P@30Hz (with one display connected)
Max Resolution (HDMI/DP): 1920x1080P@60Hz (with two displays connected)
Max Resolution (HDMI/DP): 1920x1080P@60Hz (with three displays connected)
Max Resolution (VGA): 1920x1080P@60Hz (with one or two displays connected)
Max Resolution (VGA): 1280x720P@60Hz (with three displays connected)
Max Data Rate (HDMI/DP output): 10.2Gbps (3.4Gbps per graphic channel)
Multiple Video Output Support: Via MST (Multi–Stream Transport) technology
Content Protection (HDMI output): HDCP 1.4

EXTENDED ETHERNET
Max Data Rate: 1000M (Gigabit)/100M/10M
Includes: Wake–on–LAN (WoL), single Mac address, PXE boot

ALGEMEEN
USB 3.0 Data Transmission Speed: Up to 5.0Gbps

VOEDING
Delivery: 100W
USB Charging: BC1.2 (5V 1.5A)
USB Limited Current when Connected to Power via female USB-C port: 1.9A
USB Limited Current when Not Connected to Power via female USB-C port: 1A
ENVIRONMENTAL CONDITIONS

Operating Temperature: 0° to +70°C (32° to 158°F)
Storage Temperature: –10° to +55°C (14° to 131°F)
Humidity: 5% to 90%, RHL non–condensing

ENCLOSURE
Type: Aluminum with built–in 20cm/7.87″ flexible USB–C cable
REGULATORY COMPLIANCE (STANDARDS COMPLIANCE)

Safety: CE
Environmental: RoHs, FCC

PRODUCT DIMENSIONS
26.00cm x 9.00cm x 2.50cm (10.24″ x 3.54″ x 0.98″ ) W, D, H

PRODUCT WEIGHT
0.4kg (0.8lbs) approx.

SHIPPING DIMENSIONS
31.80cm x 13.00cm x 3.10cm (12.52″ x 5.12″ x 1.22″ ) W, D, H

SHIPPING WEIGHT
0.5kg (1.0lbs) approx.
